Description

Ideal for surgeries in medium and large surgery rooms, the MI-1000 surgery light offers unsurpassed longevity and flexibility in an affordable package. The large-diameter LED array provides exceptional shadow control, while controlling brightness within the illumination field is simple, with a 5-stage dimming control handle.

The MI Series features arms that provide a wide 11-foot circle of reach, along with smooth movement, maneuverability, and advanced mounting system.

Output rated at 100,000 LUX
4,300° Kelvin pure white illumination
CRI (Color Rendering Index) of 97
Superior shadow control
High efficiency with half the electric consumption of standard halogen lights
Five-stage dimming and on-off switch controlled from sterilizable handle
Long-life LEDs, rated at 50,000 hours
Lower overall maintenance costs
Near-zero radiated heat
Wide array of mounts for extreme flexibility

Specifications

Weight & Dimensions

Light Head Weight: 14.8 lb (6.7 kg)
Light Head Diameter: 18” (45.7 cm)
Floor Stand Height: 74.5” (189 cm)
Shipping Weight(2 boxes): 62 lb (28.12 kg) / 17 lb (7.7 kg)
Shipping Dimensions: (2 boxes):
36” (L) x 23” (W) x 18” (H) (91.4 cm x 58.4 cm x 46 cm).
77” (L) x 6” (W) x 6” (H) (196 cm x 15.2 cm x 15.2 cm).

Rotation

Arm Rotation: 540°.
Light Head Rotation: 300°.

Power & Light Output

Power Supply Circuit: 100 – 240 VAC, 50 / 60 Hz.
Power Handling Capacity: 100 W.
Light Intensity Output: 100,000 lux (9,290 footcandles).
Light Source: Light Emitting Diode (LED) (54 W).
Rated LED Lifespan: 50,000 hours.
Number of LED: 36.
Light Color Temperature: 4,300 Kelvin.
Color Rendering Index: 97.
Light Field Diameter: 8.3” (21 cm).
Focal Length: 39.4” (1 m).
Depth of Illumination: 24” (61 cm).
Dimming Levels: 5.
- Level 5 (100%): 100,000 lux (9,290 footcandles).
- Level 4 (87%): 87,500 lux (8,129 footcandles).
- Level 3 (75%): 75,000 lux (6,968 footcandles).
- Level 2 (62%): 62,500 lux (5,806 footcandles).
- Level 1 (50%): 50,000 lux (4,645 footcandles).
