Highdent Cinco Plus Dental Unit

Specifications

Specifications

Air/Water Syringe

• Lightweight, compact contoured head
• Quick connect-disconnect tip
• Uses standard autoclavable tips
• 360º tip rotation
• Precise control of air, water, and mist

Piezo Scaler

• Totally autoclavable and easy to dismantle.
• LED Piezo is available as an option.

Ergonomics

• Simple and easy adjustment of the handpiece console to the desired angle.

Automatic selection of handpieces

• No waste of time selecting the handpiece.

Shelf

• More space for your instruments.
• No joints, seals, or visible screws, for easier cleaning.
• Rounded edge to prevent your instruments from falling.
• 12,5” x 17,5” (32 cm x 44,5 cm).

Suction

• Detachable suction hose for easier cleaning.
• Stronger suction.
• More flexible hose for ease of use.

Adjustable height

• From 31” to 41” (78.7 cm to 104 cm).

Foot control

• Control the handpieces and suction.
• Protective guard.

Muffler

• Highdent™ dental machines include a muffler to reduce noise from the handpieces

Mobile and Secure

• 5.08cm (2”) castors with brakes

Compressor

• The quietest on the market.
• Very easy access to drain valves.
• The fastest oil change in the industry.
• Airflow: 2.1 cubic feet per minute.

110V with oil model

• Amps: 7.0 A
• Power Source: 120 V AC
• Operaring frequency: 50-60 Hz

230V with oil model

• Amps: 4.0 A
• Power Source: 230 V AC
• Operaring frequency: 50-60 Hz

Conforms and Certified

Conforms to UL STD 61010-1
Certified to CSA STD C22.2 No. 61010-1
Intertek No. 4009746

Optional features

• Wall-mount
