Description

The Bovie OR|PRO 300 Veterinary Electrosurgical Generator (Model A3350-V) is a state-of-the-art, 300-watt electrosurgical unit engineered to deliver exceptional precision, safety, and versatility for advanced veterinary surgical procedures. Designed in collaboration with operating room clinicians, this high-performance generator is tailored to meet the rigorous demands of veterinary operating suites, supporting a wide range of procedures including general surgery, orthopedic, ENT, urologic, and laparoscopic interventions. With 13 distinct energy delivery modes, including specialized Bovie Bipolar, Auto Bipolar, and Laparoscopic modes, the A3350-V empowers veterinary surgeons to customize energy settings for optimal outcomes across diverse species and surgical applications.

The OR|PRO 300 prioritizes safety with cutting-edge features like BovieNEM™ (Neutral Electrode Monitoring) for real-time pad connectivity, BovieFDFS™ (Fast Digital Feedback System) for precise tissue impedance adjustments, and BovieDED™ (Digital Error Detection) to ensure continuous safety for patients, veterinarians, and staff. Its Cut II mode is specifically optimized for laparoscopic procedures, reducing the risk of capacitive coupling and alternate site burns, making it ideal for minimally invasive veterinary surgeries. The intuitive interface, featuring large illuminated digital displays and tactile controls, allows for rapid adjustments, while the unit’s compact, lightweight design (20 lbs) and stackability enhance its practicality in busy veterinary clinics. With compatibility for industry-standard accessories and a 4-year warranty, the Bovie OR|PRO 300 is a reliable, cost-effective solution for veterinary practices seeking operating-room-grade performance.

Veterinary Advantages

Versatile Applications: Supports a broad spectrum of veterinary procedures, from soft tissue surgeries in small animals (e.g., spays, tumor removals) to orthopedic interventions in large animals (e.g., equine joint surgeries), as well as general surgery, ENT, urologic, laparoscopic, neurosurgery, and ophthalmic procedures. It ensuring precise cutting and coagulation across numerous species.
Laparoscopic Precision: The specialized Cut II and Laparoscopic modes minimize tissue trauma and enhance safety in minimally invasive procedures, critical for delicate veterinary surgeries like ovariectomies or biopsies.
Advanced Bipolar Modes: Bovie Bipolar and Auto Bipolar modes provide pulsing and self-limiting coagulation, ideal for precise hemostasis in neurosurgery or ophthalmic procedures on animals.
Safety for Diverse Patients: BovieNEM™ and BovieFDFS™ adapt to varying tissue impedances in different species, ensuring safe energy delivery for small exotics to large mammals.
User-Friendly for Veterinary Teams: The intuitive interface and memory for last-used settings streamline setup in high-pressure surgical environments, reducing downtime in busy clinics.

Additional Features

Compact and stackable design for space-efficient storage in veterinary clinics
Specialized Cut II and Laparoscopic modes for minimally invasive veterinary surgeries
Advanced Bovie Bipolar and Auto Bipolar modes for precise coagulation in delicate procedures
Compatible with most industry-standard electrosurgical accessories
Optional mobile stand (BV-IDS-CS, sold separately) for enhanced portability

Accessories Included

(1) Disposable Electrosurgical Push Button Pencil – Blade – Standard (ESP1)
(1) Disposable Standard Blade Electrode (ES01)
(1) Disposable Standard Needle Electrode (ES02)
(1) Disposable 3/16″ Ball Electrode (ES20)
(5) Disposable Split Adult Return Electrodes – Standard (ESRE)
(2) Reusable Connecting Cords (A1252C: ESRE/ESRS)
(1) 110 VAC Hospital-Grade Power Cord, 15 ft (09-039-001)
(1) 220 VAC Hospital-Grade Power Cord, 15 ft (09-035-001)
User’s Guide in CD format (MC-55-230-001)

Technical Specifications

Technical Specifications: Bovie OR|PRO 300 Veterinary Electrosurgical Generator (A3350-V)

Model: A3350-V
Power Output:
- Cut I: 300 watts @ 500 Ω
- Cut II: 200 watts @ 300 Ω (optimized for laparoscopic procedures)
- Blend: 200 watts @ 300 Ω (adjustable in 10 steps)
- Pinpoint Coagulation: 120 watts @ 500 Ω
- Spray Coagulation: 80 watts @ 500 Ω
- Gentle Coagulation: 120 watts @ 125 Ω
- Macro Bipolar: 80 watts @ 100 Ω
- Micro Bipolar: 80 watts @ 100 Ω
- Standard Bipolar: 50 watts @ 100 Ω
- Auto Bipolar: 80 watts @ 100 Ω
Output Modes:
- Monopolar: Cut I, Cut II, Blend (10 settings), Pinpoint Coagulation, Spray Coagulation, Gentle Coagulation
- Bipolar: Macro Bipolar, Micro Bipolar, Standard Bipolar, Auto Bipolar
Line Voltage: 100–240 VAC (auto-sensed)
Line Frequency: 50–60 Hz
Output Frequency: 490 kHz ± 5
Weight: 20 lbs (9.1 kg)
Dimensions: 14.75″ (W) x 18.1″ (D) x 6.5″ (H) (37.5 cm x 46 cm x 16.5 cm)
Safety Features:
- BovieNEM™ (Neutral Electrode Monitoring): Monitors return electrode connectivity, critical for safe energy delivery in veterinary patients of varying sizes
- BovieFDFS™ (Fast Digital Feedback System): Dynamically adjusts power based on tissue impedance, ensuring precision across diverse animal tissues
- BovieDED™ (Digital Error Detection): Continuously monitors system functions to prevent errors, enhancing safety for veterinarians and patients
- FCFS™ (First Come, First Served): Ensures only one output is active at a time to prevent unintended activation
- Isolated RF Output: Minimizes risk of alternate site burns, crucial for delicate veterinary procedures
- Self-Test Circuits: Continuously monitor unit performance
- Audible and Visual Alarms: Notify users of system status or errors
Display: Large, illuminated digital displays for clear visibility in surgical environments
Controls: Tactile push-button power controls for rapid, precise adjustments
Memory: Recalls last selected power settings for Cut and Coag modes, streamlining setup for repeated veterinary procedures
Compatible Accessories:
- Disposable Electrosurgery Pencils
- Disposable LLETZ/LEEP Loop Electrodes
- Disposable Extended Ball Electrodes
- Disposable SuperCut Needle Electrodes
- Disposable Resistick II Electrodes
- Disposable Dermal Loops
- Smoke Evacuation Systems (e.g., Bovie Smoke Shark II, recommended for veterinary procedures generating surgical smoke)
Safety Standards:
- IEC 60601-1
- IEC 60601-2-2
- IEC 60601-1-2
ContactಸContact Monitoring Systems Range/Trip Point: 10 ohms or less over entire operating range (10°C to 40°C)
Warranty: 4 years limited (free from defects in material and workmanship)

Bovie OR PRO A3350-V Veterinary Electrosurgical Generator
