The Excelis™ HD camera offers clear 1080P HD video, 6MP image capture, and live recording. It includes built-in software for easy control and measurement without a computer. The AU-600-HDS version has an attached 11.6” HD monitor for space-efficient viewing.
The Excelis™ HD camera offers clear 1080P HD video, 6MP image capture, and live recording. It includes built-in software for easy control and measurement without a computer. The AU-600-HDS version has an attached 11.6” HD monitor for space-efficient viewing.
Specifications:
Sensor: Sony IMX307, CMOS, color
Sensor Size: 1/2.8”, 0.5x or 0.35x C-mount (recommended)
Live Resolution: 1920 (H) x 1080 (V)
Frame Rate: HDMI: 60fps; USB 2.0: 30fps
Image Capture: 6MP (3264×1840) to highspeed 8GB SD card (included); or USB 2.0 to PC
Video Capture: HDMI: 1080p, 60fps, 30fps to SD Card USB 2.0: 6MP, 30fps to PC or Mac
Exposure Time: Auto; 0.001 sec – 10.0 sec
White Balance: Auto / area / manual
Settings: Gain, gamma, saturation, brightness, sharpness
Built-in Software: Cloud 1.0
PC and Mac Imaging Software: CaptaVision+ Imaging Software for PC and Mac OS
Advanced Camera Controls: live/still image measurement and annotation; scale bar, flat field correction; extended depth of focus (focus stacking); image stitching; HDR (high dynamic range) function
Image Types: JPG, PNG, TIF & DICOM (DICOM not available for Mac) TWAIN driver available
System Software Compatibility: Windows 7, 8, 10 & 11
(64-bit recommended)
Mac OSX 10.4 and higher
System Recommendations: intel i5 or better (Quad Core or better); 16GB RAM or more; USB 2.0 high-speed port minimum (USB 3.0 recommended)
